SK200XDL

SK200XDL-10

Engine	Model	Bucket Capacity
118 kW / 2,000 min^-1 (ISO 14396)	HINO J05ETG-KSSG	0.93 m³

Engine	118 kW / 2,000 min^-1 (ISO 14396)
Model	HINO J05ETG-KSSG
Bucket Capacity	0.93 m³

This series can be used for industry:: Forestry; Agribusiness

Download Brochure: SK200XDL-10.PDF

Main Specifications

Model Name		SK200XDL
Machine Type		SK200XDL-10

Engine

Model		HINO J05ETG-KSSG
Type		Direct injection, water-cooled, 4-cycle, 4-cylinder diesel engine with intercooler turbo-charger
Power output	kW/min^-1	114 / 2,000 (ISO 9249) 118 / 2,000 (ISO 14396)

Hydraulic System

Hydraulic Oil Tank	L	System 244 / Tank level 140
Pump Type		Two variable displacement pumps + One gear pump
Pump Max.Discharge flow	L/min	220 x 2, 21 x 1

Swing System

Swing speed	min^-1{rpm}	13.3

Travel System

Travel Speed (high/low)	km/h	6.0 / 3.6
Drawbar Pulling Force	kN	228
Gradeability	% ( º )	70 {35}
Travel motors		2 x axial-piston, two-step motors

Refilling Capacities & Lubrications

Fuel Tank	L	320

Attachments

Bucket capacity ISO heaped	m³	0.93

Operating Weight

Operating Weight	kg	21,800 *1

*1 Without including weight of protective guards *Power Boost engaged
