SK50P

SK50P-6

Engine	Model	Bucket Capacity
29.6 kW/ 2,400 min^-1 (ISO14396)	YANMAR 4TNV88-B	0.14 m³

Engine	29.6 kW/ 2,400 min^-1 (ISO14396)
Model	YANMAR 4TNV88-B
Bucket Capacity	0.14 m³

This series can be used for industry:: Construction & Civil Works; Agribusiness

Download Brochure: SK50P-6.PDF

Main Specifications

Model Name		SK50P Canopy
Machine Type		SK50P-6

Engine

Model		YANMAR 4TNV88-B
Type		Water-cooled, 4 cycle, 4 cylinder direct injection type diesel engine
Rated power output	kW/min^-1	Net 29.6 / 2,400 (ISO14396) Net 28.3 / 2,400 (ISO9249)

Hydraulic System

Hydraulic capacity	L	System 57.7 / Tank 27.9
Pump Type		Tandem variable displacement piston pumps
Pump Relief Valve Setting	MPa{kgf/cm²}	23.0 {235}

Swing System

Swing speed	min^-1{rpm}	8.8 {8.8}
Swing motors		1 x axial piston type

Travel System

Travel Speed (high / low)	km/h	3.7 / 2.1
Travel motors		2 x axial piston type

Refilling Capacities & Lubrications

Fuel Tank	L	75

Dozer Blade

Width x Height	mm	1,960 x 345
Working ranges (Height : Depth)	mm	375 x 385

Side digging mechanism

Type		Boom swing
Offset Angle		70 / 59

Attachments

Bucket capacity	m³	0.14
Bucket Width (with side cutter)	mm	560 (600)

Operating Mass & Ground Pressure

Operating Mass (canopy)	kg	4,720
Ground Pressure (canopy)	kPa{kgf/cm²}	27.4 {0.28}
